Masoneilan 28000 Series Varipak™ Valve
Designed specifically for low flow applications, the Masoneilan Varipak Control Valves provides excellent throttling control performance with a wide range of options and capabilities. Design optimization has also resulted in an extremely integrated and compact assembly. Key features and benefits of the VariPak control valves include: Heavy Top-Guiding Rugged Application Flexibility Adjustable CV Compact Assembly Anti-Cavitation Trim Design flexibility
Kategori: Control Valves
Brand: Masoneilan
Masoneilan 28000 Series Varipak™ Valve Size 1” (25 mm) standard 1/2” through 3/4” (15 through 20 mm) available on request Ratings & Connections Flanged: ANSI 150 - 1500 Flangeless for mounting between flanges: ANSI 150 – 2500, UNI-DIN 10 - 400 Screwed: NPT 1/2” through 1” (15 through 25 mm) Body Materials stainless steel; monel; hastelloy C; alloy 20 Actuators integral spring diaphragm Trim full stellite needle plug; multistep anti-cavitation trim available Inherent Characteristics linear
