Wet Gas Meter Shinagawa
W-NK type for experimentation/environmental measurement Both measurement drum and case is made of stainless steel as standard; therefore, it has high durability and resistance to corrosion. Anti Corrosion type BE ( For environmental measurement) Casing, Measurement Drum, other parts: Stainless steel(SUS 304) Jointing: Soldering, Argon Weld Pressure loss : 150Pa Operating Pressure Limits : 0kPa to 10kPa Operating Temperature Limits : 4℃ to 50℃ Accuracy(repeatability) : More than 1/2 Qmax ±0.15% (Standard deviation) Less than 1/2 Qmax ±0.1% (Standard deviation) Specification Model : W-NK-1BE Measuring range (L) : 0.033～ 10 L/min ( 2 ～ 600L/h) Diaphragm Capacity (L) : 1 One Revolution (L) : 1 Minimum Scale (mL) : 1 Connecter : φ 9.5
Kategori: Meter GAS
Brand: SHINAGAWA - TOKYO
Pressure loss : 150Pa Operating Pressure Limits : 0kPa to 10kPa Operating Temperature Limits : 4℃ to 50℃ Accuracy(repeatability) : More than 1/2 Qmax ±0.15% (Standard deviation) Less than 1/2 Qmax ±0.1% (Standard deviation) Specification Model : W-NK-1BE Measuring range (L) : 0.033～ 10 L/min ( 2 ～ 600L/h) Diaphragm Capacity (L) : 1 One Revolution (L) : 1 Minimum Scale (mL) : 1 Connecter : φ 9.5
